Injector Dynamics ID1050X 1065CC Fuel Injectors for Supra MKIV TT 1050.20.05.60.14.6

Write a Review
MSRP: $966.42
$819.00
(You save $147.42 )
SKU:
1050.20.05.60.14.6

The ID1050X is the evolution of the ID1000, and the latest addition to the X-Series. It is the most recent offering from the partnership of Injector Dynamics and Bosch Motorsport, and is the result of lessons learned during development of the ID1300X, and ID1700X.

Like the ID1300X and ID1700X, the ID1050X is not a modified production component. It is a built to spec motorsport injector, offering optimization of critical operating parameters important to you, the motorsport tuner.

Compared to the original ID1000, the ID1050X offers numerous improvements, and is sure to become the new reference.

  • Corrosion resistant internals make it compatible with all known fuels, capable of extended service life with corrosive fuels.

  • Compact body allows fitment in 200+ applications, including current and future engines utilizing short body injectors.

  • Improved internal flow path increases output by 5% without sacrificing low flow performance.

  • Stronger magnetic circuit offers stable operation up to 10 bar.

  • Replaceable inlet filter extends service life.

Basic Specifications

Nominal Flow Rate û 1065cc/min @ 3.0 Bar (43.5 psi) Using Gasoline at 52 Degrees C (125 Degrees F)
Maximum Differential Fuel Pressure û 10.0 Bar (145.0 psi)
Fuel Compatibility û Compatible With All Known Fuels
Electrical Connector û USCAR

Estimated Ethanol Rating:
702.9 Horsepower
Estimated Gasoline Rating:
1086.3 Horsepower
Gasoline Horsepower Range:
800-1200 Horsepower, 1000-1400 Horsepower
E85 Horsepower Range:
400-800 Horsepower, 600-1000 Horsepower
Injector Type:
Top Feed
Injector Harness:
Plug and Pins
Injector Inlet Size:
14mm
Injector Height:
60mm
Impedance:
High
e85 Compatible:
Yes
injector cc:
1065cc
injector cc range:
750-1250cc, 1000-1500cc
Notes:
ID1050x, for Supra Turbo 93-98 / 2JZ-GTE applications. Currently top fed. 14mm (purple) top. Set of 6.
  • 1993-1998 Toyota Supra TT

Compatible Engines
  • 2JZ-GTE
  • 2JZ-GTE VVTi
